Analyze and design structural steel connections in seconds

RAM Connection is the ideal solution when structural engineers or designers need to check a specific connection, design a single connection for multiple joints, or optimize each connection in a structure. Analyze, design, and verify structural steel connections, all with comprehensive calculations, including seismic compliance.

Bentley RAM Connection enables integrated connection design by allowing integration with RAM Structural System, RAM Elements, and STAAD.Pro, or it can be used as a standalone for steel connection design.

Automate connection design

Design, check, and optimize shear, moment, gusset, splice, bracket, base plate, and truss connections, according to AISC (ASD or LRFD), EN 1993, BS 5950, IS 800, GB 50017, AS4100, and NZS 3404, automatically. Assign connections directly to the finite element model and RAM Connection will automatically consider member geometric and material properties and analytical results. RAM Connection makes it easy to check a specific connection or all connections in groups.

Embrace unlimited flexibility

Bring together your own firms’ standards to customize your design, or choose from a large database of predefined connections. RAM Connection also provides reports with explicit equations and references to the design standard.

Design connections of all types

Design shear, moment, combined connections, gusset, or truss connections and RAM will perform all the design checks so it’s easy to compare different connection options.

View your design in 3D

Cutting-edge graphics allow accurate 3D views of fit-up and clearance to reduce on-site connection issues ensuring that your structure will work in the real context of the design.
